HV430FHB-N10

Product Item : HV430FHB-N10
Category： 43inch
HV430FHB-N10
for BOE open cell
Product description：HV430FHB-N10
INQUIRY EMAIL

Product Description

Brand: BOE
Model P/N: HV430FHB-N10

Diagonal Size: 43"
Panel Type: a-Si TFT-LCD, CELL , FOB

Resolution: 1920(RGB)×1080, FHD 51PPI
Pixel Format: RGB Vertical Stripe

Active Area: 940.896(W)×529.254(H) mm
Bezel Opening: -

Outline Size
950.896(W)×541.75(H) ×1.4(D) mm
Surface
Antiglare (Haze 1%), Hard coating (3H)

Brightness
0 cd/m²
Contrast Ratio
1200:1 (Typ.) (TM)

Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
ADS, Normally Black, Transmissive

Best View on
Symmetry
Response Time
8 (Typ.)(G to G)

Glass Depth
0.50+0.50 mm
Transmissivity
6.3% (Typ.)(with Polarizer)

Display Colors
16.7M 72% NTSC
Lamp Type
No B/L

Frequency
60Hz
Touch Screen
Without

Driver IC
COF Built-in 6 source chips

Panel Weight
1.51Kgs (Typ.)
Application

Signal Interface
LVDS (2 ch, 8-bit) , 51 pins Connector

Input Voltage
12.0V (Typ.)

Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
