HV430QUB-H10

Product Item : HV430QUB-H10
Category： 43inch
HV430QUB-H10
BOE 43
Open Cell TV Screen Spare Panel Replacement Parts for TV Repair
Product description：HV430QUB-H10 51 pins BOE 43" inch LCD LED TFT Display Open Cell TV Screen Spare Panel Replacement Parts for TV Repair
INQUIRY EMAIL

- Product Description

Brand: BOE
Model P/N: HV430QUB-H10

Diagonal Size: 43"
Panel Type: a-Si TFT-LCD, CELL , FOB

Resolution: 3840(RGB)×2160, UHD 103PPI
Pixel Format: RGB Vertical Stripe

Active Area: 941.184(W)×529.416(H) mm
Bezel Opening: -

Outline Size: 953(W)×543(H) ×1.34(D) mm
Surface: Antiglare (Haze 1%), Hard coating (3H)

Brightness: 0 cd/m²
Contrast Ratio: 1200:1 (Typ.) (TM)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10)
Display Mode: ADS, Normally Black, Transmissive

Best View on: Symmetry
Response Time: 8 (Typ.)(G to G)

Glass Depth: 0.50+0.50 mm
Transmissivity: 4.1% (Typ.)(with Polarizer)

Display Colors: 1.07B 72% NTSC
Lamp Type: No B/L

Frequency: 120Hz (60Hz Input)
Touch Screen: Without

Driver IC: COF Built-in 6 source chips

Panel Weight: 1.58Kgs (Typ.)
Application

Signal Interface: V-by-One 8 lane , 51 pins Connector

Input Voltage: 12.0V (Typ.)

Environment: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
