Model P/N:HV430FHB-N10
Diagonal Size4:3"Panel Typea-Si TFT-LCD, CELL , FOB
Resolution:1920(RGB)×1080, FHD 51PPI
Pixel Format:RGB Vertical Stripe
Active Area940.896(W)×529.254(H) mm
Outline Dim:950.896(H)×541.75(V)×1.4(D) mm
Treatment:Antiglare (Haze 1%), Hard coating (3H)
Luminance:0 cd/m²Contrast Ratio1200:1 (Typ.) (TM)
View Direction:Symmetry
Response Time:8 (Typ.)(G to G)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
DownOperating:ModeADS, Normally Black, Transmissive
Plate Thickness:0.50+0.50 mm
It's Depth of CF Depth + Array Depth
CELL Depth = CF Depth + Array Depth
Transmittance6.3% (Typ.)(with Polarizer)
Support Color16.7M 72% NTSC
Light SourceNo B/L
Weight1.51Kgs (Typ.)Designed ForTV Sets
Frame Rate:60Hz
Power Supply:12.0V (Typ.)
EnvironmentOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
