HV320FHB-N02

Product Item : HV320FHB-N02
Category： 32inch
Product description：HV320FHB-N02
INQUIRY EMAIL

Product Description

Brand: BOE
Model P/N: HV320FHB-N02

Diagonal Size: 32.0"
Panel Type: a-Si TFT-LCD, CELL , FOB

Resolution: 1920(RGB)×1080, FHD 69PPI
Pixel Format: RGB Vertical Stripe

Active Area: 698.4(W)×392.85(H) mm
Bezel Opening: -

Outline Dim.708.4(H)×405.4(V)×1.36(D) mm
TreatmentAntiglare (Haze 1%), Hard coating (3H)

Luminance0 cd/m²
Contrast Ratio1200:1 (Typ.) (TM)

View DirectionSymmetry
Response Time8 (Typ.)(G to G)

Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Operating ModeADSDS, Normally Black, Transmissive

Plate Thickness0.50+0.50 mm
Transmittance5.0% (Typ.)(with Polarizer)

Support Color16.7M 72% NTSC
Light SourceNo B/L

Weight850g (Typ.)
Designed For

Frame Rate60Hz
Touch PanelWithout

D-IC Detail
COF Built-in 6 source chips

Interface Type
LVDS (2 ch, 8-bit) , 51 pins Connector

Power Supply
12.0V (Typ.)

Environment
Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C
