HV550QUB-S1E

• • Product Description

  Brand

  BOE

  Model P/N

  HV550QUB-S1E

  Diagonal Size

  55"

  Panel Type

  a-Si TFT-LCD, CELL , FOB

  Resolution

  3840(RGB)×2160, UHD  80PPI

  Pixel Format

  RGB Vertical Stripe

  Active Area

  1209.6(W)×680.4(H) mm

  Bezel Opening

  -

  • Outline Dim.
    1222.2(W)×695.2(H)×1.34(D) mm
  • Treatment
    Antiglare, Hard coating (2H), Antireflection

  • Luminance
    0 cd/m²
  • Contrast Ratio
    1400:1 (Typ.) (TM)

  • View Direction
    Symmetry
  • Response Time
    8 (Typ.)(G to G)

  • Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
  • Operating Mode
    ADS, Normally Black, Transmissive

  • Plate Thickness
    0.50+0.50 mm
  • Transmittance
    4.0% (Typ.)(with Polarizer)

  • Support Color
    16.7M   87% DCI-P3
  • Light Source
    No B/L

  • Weight
    2.70Kgs (Typ.)
  • Designed For


  • Frame Rate
    120Hz
  • Touch Panel
    Without

  • D-IC Detail
  • COF Built-in 12 source chips

  • Interface Type
  • CEDS , 136 pins Connector

  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C



• Our Company




Shenzhen Flylobu Electronics Technology Co., Ltd.

We are located in Shenzhen, China, specializing in Opencell, LCD modules and displays for 5 years。we have a foothold global market around

the world, Opencell and module cover the LG,SAMSUNG, PANDA,SHARP, Innolux, CSOT in major brands. Company main products size for

19-75 inches, products are widely used in TV, display, industrial control system, games monitor and other fields,the company in line with "customer

first, high quality, high quality, fast after-sales service" principle, always adhere to provide customers with high quality products, excellent service,

won the customer more satisfaction and good reputation!Warmly welcome to visit us! Warmly welcome to contact us to provide opportunity to both

of us to understand each otherwhich surely will make you realize your time spending on Flylobo is worthy.

Sincerely looking forward to be your BEST Partner in China!

• Our warehouse

•


• Packaging&Transportation

•


• FAQ

•


Q: May i get a cheaper price?
A：Yes,the more quantity you orderthe cheaper price you get.

Q: What is the delivery term?

A：FOB/EXW

Q: Do you provide samples ? is it free or extra ?
A：SorryNowe could't offer the sample for free charge But if you place an order of full container we will return the sample charge and the cost of freight

Q: What is your terms of payment ?
A：Paypal:T/T:Western Union

Q. What's the deliverv time?
A：After payment in 3-7 daysthat is up to your quanlity and models.
