CC500PV3D

• Product Description

  Brand

  PANDA

  Model P/N

  CC500PV3D

  Diagonal Size

  50"

  Panel Type

  Oxide TFT-LCD, CELL , FOB

  Resolution

  3840(RGB)×2160, UHD  89PPI

  Pixel Format

  RGB Vertical Stripe

  Active Area

  1095.8(W)×616.41(H) mm

  Bezel Opening

  -

  • Outline Size
    1106.84(W)×628.01(H) ×1.37(D) mm
  • Surface
    Antiglare, Hard coating (3H)

  • Brightness
    0 cd/m²
  • Contrast Ratio
    5000:1 (Typ.) (TM)

  • Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
  • Display Mode
    UV2A, Normally Black, Transmissive

  • Best View on
    Symmetry
  • Response Time
    8 (Typ.)(G to G)

  • Glass Depth
    0.50+0.50 mm
  • Transmissivity
    5.3% (Typ.)(with Polarizer)

  • Display Colors
    1.07B   70% NTSC
  • Lamp Type
    No B/L

  • Frequency
    60Hz
  • Touch Screen
    Without

  • Driver IC
  • COF Built-in 12 source + 12 gate chips

  • Panel Weight
    2.03Kgs (Typ.)
  • Application


  • Signal Interface
  • USI-T , 192 pins Connector

  • Environment
  • Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C

•
